Applications
Creasing and Cutting for Package Application
GCC RX II-CR is equipped with a tool holder loading the creasing tools and blades. For the applications, the cards and showcases can be simultaneously creased and cut in one time.
Applicable Models
Details
GCC Cutter Laboratory specially presents you the creasing application in this month.

GCC RX II-CR is equipped with a tool holder loading the creasing tools and blades. For the applications, the cards and showcases can be simultaneously creased and cut in one time.
Not only can save time but also create the diversified image draw and edit for a user, enabling products made by RX II-CR to present craft more than value and excellence.

In addition, RX II series combine the procedures to set color by many parameters, allowing a user to set many parameters by different colors and providing more convenience for a user when setting the parameters.

Tips:
It is recommended the card weighs from 322 to 562 gsm (200 to 350 lbs).
The weigh will change with the paper type and thickness.

Sample:

Reference Parameters:



BladeCreasing
Speed15cm/s3cm/s
Force415g600g
Length00
Offset0.250mm0mm
QualityNormalNormal
